JFC1206FS Series are the fuses set the industrystandard for performance, reliability and quality. Thesolder‐free design provides excellent on‐off andtemperature cycling characteristics during use and alsomakes our SMD fuses more heat and shock tolerantthan typical subminiature fuses.
| Part No. | Rated Voltage | Rated Current (A) | Breaking Capacity | Typical Cold. Resistance (mOhms) | Typical Voltage Drop (mV) | Typical Pre-Arcing I2 t (A2 Sec) | Aplha Marking |
| JFC1206-0250FS | 72V 63V 32V 24V | 0.25 | 50A@72V 50A@63V 50A@32V 300A@24V | 3608 | 1407 | 0.0004 | .25 |
| JFC1206-0375FS | 0.375 | 1882 | 718 | 0.0008 | E | ||
| JFC1206-0500FS | 0.50 | 1028 | 650 | 0.0019 | B | ||
| JFC1206-0750FS | 0.75 | 601 | 616 | 0.0057 | .75 | ||
| JFC1206-1100FS | 1.0 | 490 | 510 | 0.10 | H | ||
| JFC1206-1150FS | 1.5 | 240 | 367 | 0.15 | K | ||
| JFC1206-1200FS | 2.0 | 132 | 316 | 0.41 | N | ||
| JFC1206-1250FS | 2.5 | 77 | 240 | 0.65 | O | ||
| JFC1206-1300FS | 3.0 | 48 | 187 | 1.39 | P | ||
| JFC1206-1350FS | 3.5 | 40 | 180 | 1.68 | R | ||
| JFC1206-1400FS | 4.0 | 35 | 173 | 1.73 | S | ||
| JFC1206-1450FS | 32V 24V | 4.5 | 150A@32V 300A@24V | 30 | 164 | 2.62 | X |
| JFC1206-1500FS | 5.0 | 25 | 141 | 2.89 | T | ||
| JFC1206-1600FS | 6.0 | 16.5 | 142 | 11.0 | F | ||
| JFC1206-1700FS | 7.0 | 12 | 140 | 12.5 | 7 | ||
| JFC1206-1800FS | 8.0 | 8.5 | 110 | 14.0 | M | ||
| JFC1206-2100FS | 10 | 6.8 | 100 | 20.0 | U | ||
| JFC1206-2120FS | 12 | 5.0 | 85 | 11.5 | 12 | ||
| JFC1206-2150FS | 15 | 3.9 | 78 | 16.5 | 15 | ||
| JFC1206-2200FS | 20 | 1.8 | 60 | 47.14 | 20 | ||
| JFC1206-2250FS | 25 | 1.6 | 90 | 60 | L | ||
| JFC1206-2300FS | 30 | 1.3 | 90 | 100 | Z | ||
| JFC1206-2400FS | 24V 32V | 40 | 200A@32V 200A@24V | 0.85 | 95 | 160 | XL |
